ADA 101- Minimum Required Depth

ADA 101 info graphic with ADAS 2010 section 306.2.3 code text and example pictures2010 ADAS 306.2.3 Minimum Required Depth

Where toe clearance is required at an element as part of a clear floor space, the toe clearance shall extend 17 inches minimum under the element.

Code according to 2010 ADAS. Check your state’s accessibility laws. Some states such as California, Georgia and Florida have additional requirements and standards.

ADA 101 – T Shaped Space

ADA 101 info graphic with ADAS 2010 section 304.3.2 code text and example pictures

2010 ADAS 34.3.2 T-Shaped Space

The turning space shall be a T-shaped space within a 60 inch square minimum with arms and base 36 inches wide minimum. Each arm of the T shall be clear of obstructions 12 inches minimum in each direction and the base shall be clear of obstructions 24 inches minimum. The space shall be permitted to include knee and toe clearance complying with 306 only at the end of either the base or one arm.

Code according to 2010 ADAS. Check your state’s accessibility laws. Some states such as California, Georgia and Florida have additional requirements and standards.

MTA Plan Expands List of NY Subway Stations to get Accessibility Improvements

Subway station with stairs

Accessibility and compliance with the ADA was front and center for the Metropolitan Transportation Authority (MTA) in 2019. With as many as four lawsuits challenging the MTA’s subway accessibility record the MTA has been working to correct the situation. In a series of announcements the MTA, the largest public transit authority in the United States, has expanded on its original accessibility improvement plan.

On April 20, 2018: “The MTA Board approved a capital plan amendment today that significantly increases the agency’s investment in ADA accessibility projects as part of the 2015-2019 MTA capital plan.”

On September 19, 2019: “MTA Commuter Railroads Announce the Addition of 11 ADA-Accessible Stations as Part of 2020-2024 Capital Plan”

Most recently on December 19, 2019: “MTA Announces 20 Additional Subway Stations to Receive Accessibility Improvements Under Proposed 2020-2024 Capital Plan”

Public transportation is a major resource for people of all abilities and with our aging population it is sure to see even greater demand in the years to come. Funding such long term initiatives is frequently a challenge. A challenge the MTA is taking head on, setting a foundation for a more inclusive and accessible public transportation in the future.

Sources: MTA Press Releases
http://www.mta.info/press-release/mta-headquarters/mta-board-approves-additional-funding-subway-station-ada
http://www.mta.info/press-release/mta-headquarters/mta-commuter-railroads-announce-addition-11-ada-accessible-stations
http://www.mta.info/press-release/mta-headquarters/mta-announces-20-additional-subway-stations-receive-accessibility

ADA 101 – Curb Ramp Landings

ADA 101 info graphic with ADAS 2010 section 406.4 code text and example pictures

2010 ADAS 406.4 Curb Ramp Landings

Landings shall be provided at the tops of curb ramps. The landing clear length shall be 36 inches minimum. The landing clear width shall be at least as wide as the curb ramp, excluding flared sides, leading to the landing.

EXCEPTION: In alterations, where there is no landing at the top of curb ramps, curb ramp flares shall be provided and shall not be steeper than 1:12.

Code according to 2010 ADAS. Check your state’s accessibility laws. Some states such as California, Georgia and Florida have additional requirements and standards.



ADA 101 – Sides of Curb Ramps

ADA 101 info graphic with ADAS 2010 section 406.3 code text and example pictures

2010 ADAS 406.3 Sides of Curb Ramps

Where provided, curb ramp flares shall not be steeper the 1:10 (10%).

Code according to 2010 ADAS. Check your state’s accessibility laws. Some states such as California, Georgia and Florida have additional requirements and standards.



ADA 101 – Passing Spaces

ADA 101 info graphic with ADAS 2010 section 403.5.3 code text and example pictures

2010 ADAS 403.5.5 Passing Spaces

An accessible route with a clear width less than 60 inches shall provide passing spaces at intervals of 200 feet maximum. Passing spaces shall be either: a space 60 inches minimum by 60 inches minimum; or, an intersection of two walking surfaces providing a T-shaped space complying with 304.3.2 where the base and arms of the T-shaped space extend 48 inches minimum beyond the intersection.

Code according to 2010 ADAS. Check your state’s accessibility laws. Some states such as California, Georgia and Florida have additional requirements and standards.

ADA 101 – Extended Floor or Ground Surface

ADA 101 info graphic, with ADAS 2010 section 405.9.1 code and example pictures

2010 ADAS 405.9.1 Extended Floor or Ground Surface

The floor or ground surface of the ramp run or landing shall extend 12 inches minimum beyond the inside face of a handrail complying with 505.

Code according to 2010 ADAS. Check your state’s accessibility laws. Some states such as California, Georgia and Florida have additional requirements and standards.

ADA 101 – Curb or Barrier Edge Protection

ADA 101 info graphic, with ADAS 2010 section  404.2.4.3 code and example pictures2010 ADAS 405.9.2 Curb or Barrier Edge Protection

A curb or barrier shall be provided that prevents the passage of a 4 inch diameter sphere, where any portion of the sphere is within 4 inches of the finish floor or ground surface.

Code according to 2010 ADAS. Check your state’s accessibility laws. Some states such as California, Georgia and Florida have additional requirements and standards.

ADA 101 – Recessed Doors and Gates

Info graphic with ADAS 2010 Section 404.2.4.3 text and example pictures2010 ADAS 404.2.4.3 Recessed Doors and Gates

Maneuvering clearances for forward approach shall be provided when any obstruction within 18 inches of the latch side of a doorway projects more than 8 inches beyond the face of the door, measured perpendicular to the face of the door or gate.

Code according to 2010 ADAS. Check your state’s accessibility laws. Some states such as California, Georgia and Florida have additional requirements and standards.

ADA 101 – Clear Width at Turn

ADA 101 Info graphic with ADAS 2010 403.5.2 text and example pictures2010 ADAS 403.5.2 Clear Width at Turn

Where the accessible route makes a 180 degree turn around an element which is less than 48 inches wide, clear width shall be 42 inches minimum approaching the turn, 48 inches minimum at the turn and 42 inches minimum leaving the turn.

EXCEPTION: Where the clear width at the turn is 60 inches minimum compliance with 403.5.2 shall not be required.

Code according to 2010 ADAS. Check your state’s accessibility laws. Some states such as California, Georgia and Florida have additional requirements and standards.
